Product Specifications
| Working distance | 0.1m-2.5m @90% reflectance |
| LED Operating Wavelength | 940nm |
| Dimensions | 52*26*26.6 mm |
| Supported Systems | Linux Ubuntu14.04/16.04,Windows X86/X64 |
| Accuracy | ±1.5cm @10cm-50cm;≤1.5% @50cm-2.5m |
| Output interface | USB 2.0 |
| RGB | FOV | 110°(H)*59°(V) |
| Resolution | 1280*720 | |
| Frame Rate | 10fps | |
| Depth | FOV | 120°(H)*56°(V) |
| Resolution | 224*109 | |
| Frame Rate | 10fps@224*109 |
Contact Us
Sunny Optical has deployed technologies and products based on the two application areas of identification and positioning. The scenario applications cover XR and smart wearables, robots, AIoT (smart home, smart business, smart logistics, etc.). Welcome to contact us, you can add WeChat ID: shunyuzng.
